The Role of the Prisoner Elevator in Courthouse Circulation

by Ted Prestogeorge / April 18, 2019



There are three separate circulation paths in a well-designed modern courthouse: circulation for judges, the public, and prisoners. Each of these circulation paths cannot cross another. However, like a brain-teaser puzzle where you need to draw a shape without crossing lines, how can you design the three separate circulation paths without “crossing lines?”

Keeping two separate circulation paths – say for judges and the public – is easy. This could be designed as a “front of the house” and “back of the house” layout, where the public circulation to the courtroom is in the front and the judges’ circulation from chambers to the bench is in the back. However, prisoner movement requires being securely transported to the courtroom holding cell and courtroom, which are located between, and are surrounded by, the other two circulation paths. How do you get the prisoners securely into this “in-between” space without coming from the front of the house (crossing the public’s circulation path) or from the back of the house (crossing the judges’ circulation path)?

The Prisoner Elevator

The answer is to bring prisoners from the courthouse’s sallyport and/or central lockup to the courtroom via a prisoner elevator.

The prisoner elevator should be large enough to accommodate several prisoners and at least two court law enforcement officers. In addition, the elevator should include a lockable and secure caged partition to separate the prisoners from law enforcement – essentially a cell within the elevator, as seen in the image below. The enclosed space of the elevator cab can make for an unsafe situation if law enforcement personnel are forced to stand shoulder-to-shoulder or in otherwise close proximity to prisoners.


Large prisoner elevator with interior caged partition

I was in an older courthouse that had a very small and unpartitioned prisoner elevator that two people – one law enforcement officer and one prisoner – could barely squeeze into. The officer showing me the space confided to me that even though they are trained officers who are not easily intimated, he and his fellow officers always feel a little uneasy when confined in that elevator with a prisoner.

Prisoner Elevator Location and Prisoner Corridors

In the diagram below, the prisoner spaces and circulation, including the path of the prisoner elevator shaft, are shown in red for a layout in which the courtrooms line up vertically with the central cellblock.




Separation of circulation paths in a courthouse

What if the courtrooms and their associated holding cells are not in line vertically with the cellblock? Or how would this work for courtroom holding cells in larger courthouses that may have multiple groupings of courtrooms that may not all line up with the central cellblock?

The floor plans below show an example of such a courthouse. Each of the two prisoner elevators is located directly below each pair of courtrooms, and they are not located within the secure central cellblock. However, they still need to be accessed from the cellblock via secure prisoner corridors. At first glance, it seems a solution could be to provide a secure prisoner corridor from the cellblock to each elevator. However, as the first set of floor plans below shows, this solution would result in the prisoner corridor cutting through first floor space that is well suited for courthouse offices. This would bisect parts of that prime office space by an impenetrable corridor, disturbing internal circulation patterns of the office.


Poorly laid-out prisoner corridor

If a secure prisoner corridor cannot be provided on the first floor without disrupting the smooth flow of operations within the office spaces, where can the prisoner corridor go? One answer would be to go down first to access the elevators before going up to the courtrooms.

The building layout in the floor plans below is virtually identical to the floor plans above except a third prisoner elevator has been added that transports prisoners down to a sub-basement. In the sub-basement is a secure prisoner corridor connecting the third elevator to the two elevators that are aligned with the courtroom holding cells on the second floor above.


Properly laid-out prisoner corridor

I recently saw another solution to this secure corridor issue in a courthouse in California. In that courthouse, instead of a sub-basement, the secure prisoner corridors connecting the two prisoner elevators were on a mezzanine space above the first floor. I thought this was a great idea. Let me explain how this works.

Often a courthouse design will include an extra-high first floor to give the entry and public lobby space a sense of volume. However, not all of the first floor is part of the lobby; much of it tends to be used for offices that don’t require high ceilings. That extra height space becomes hidden and unused in the space above the office ceilings. The California courthouse took advantage of the otherwise hidden space and put it to use. A mezzanine was constructed above a portion of the first floor, just large enough for a long secure corridor connecting one prisoner elevator on one end of the building with another prisoner elevator on the other end. As in the floor plans above, putting that long corridor on an occupied floor would have had a highly negative impact on any potential office spaces on that floor.

Courthouses Differ, but the Concepts are the Same

Depending on the overall layout of the courthouse, there may be specific alternatives to these solutions, but all should use these same basic concepts, as illustrated above, for safe and secure prisoner movement:

  • Keep all prisoner movement separate from the circulation paths of judges, staff, and the public.
  • Provide dedicated prisoner elevators that are large enough, secure, and that include a lockable partitioned area for prisoners.
  • When long prisoner movement corridors are required to connect all prisoner elevators through secure circulation, locate the corridors where they will not disrupt the prime usable space within a courthouse.
